FEATURES

● Wide range of operating voltage from AC 210V/50Hz to 250V/50Hz. ● For checking AC voltage. ● For checking a RCD tester's test current & time in mA(ms). ● For checking a loop tester. ● For wiring check (Phase, Neutral, Earth). ● For checking continuity. ● For checking insulation (The maximum is 1.2kV). ● For checking UK16th edition.

SPECIFICATIONS

RCD Testing Range 10mA @ 150ms 30mA @ 150ms 150mA @ 30ms Insulation Testing   Range 1MΩ / 9.9MΩ / 99MΩ Accuracy ± 1% Max. Testing 1.2kV Continuity Testing Range 0.5Ω / 2Ω / 10Ω Accuracy ± 0.05Ω / ± 0.1Ω / ± 0.2Ω Max. Current 300mA LOOP Testing Range Supply Loop / Supply Loop +1Ω Accuracy 0.45Ω ± 0.05Ω / 1.45Ω ± 0.05Ω • Dimension: 330(L)x260(W)x160(D)mm • Weight: Approx. 2570g
